automatic forklift with 2.5ton forklift truck with huge discount CPCD25 new design

Place of Origin : Anhui, China (Mainland)

Brand Name : Vmax

Model Number : CPCD25

Certification : CE,BV,ISO,SGS

Price : 1 Set/Sets (Min. Order)

MOQ : 1 Set/Sets

Supply Ability : 5000unit

Delivery Time : 25days

Condition : New

Type : Powered Pallet Truck

Power Souce : Diesel Engine

Rated Loading Capacity : 2500kg

Max. Lifting Height : 6000mm

Min. Lifting Height : 3000mm

Fork Length : 1070mm

Fork Width : 125mm

Overall Dimensions : 2576*1170*2070mm

After-sales Service Provided : Engineers available to service machinery overseas

Color : per your request

Weight : 3780kg

Contact Now

2.5T COUNTER BALANCE DIESEL FORKLIFT TRUCK SPECIFICATION
Model Unit CPC25/CPCD25
Power type
Rated capacity kg 2500
Load center mm 500
Mast Lifting height mm 3000
Free lift height mm 240
Fork size(L*W*T) mm 1070×125×45
Tilting Angles(Front/Rear) deg 6°/12°
Front overhang mm 485

Exterior Size		 Length without fork mm 2580
Overall width mm 1160
Mast drop mm 1995
Max.lift mm 4030
Front-wheel Overhead mm 2070
Min Turning Radius mm 2230
Min.intersecting aisle mm 2000

Speeds		 Max Driving speeds km/h 17.5/20
Lifting speeds mm/s 500/530
Lowering speeds mm/s 540/550
Max.grade ability % 18
Total weight kg 3780

Tires		 Front 7.00-12-12PR
Rear 6.00-9-10PR
Wheelbase mm 1600

Tread		 Front mm 970
Rear mm 970
Min.ground clearance mm 110

Engine		 Model xinchai490BPG
Rated output kw/rpm 37/2650
Rated torque N.m/rpm 148/1800
No.of cylinder 4
Displacement L 2.54
Fuel tank capacity L 52
